Model NO: | GN‐YHA20‐FH200 | |
Camera | ||
Sensor + DSP | 1/2.9" CMOS F37 + FH8536H | |
Resolution | 1080P (1920(H)*1080(V) | |
Viewing Angle | 80~85 degree with 3.6mm Lens | |
TV System | PAL/NTSC | |
Electronic Shutter | 1/25s~1/50,000s , 1/30s~1/60,000s | |
S/N Ratio | ≥50dB | |
Video Output Mode | 4 IN 1 ( AHD/CVI/TVI 1080P, CVBS 960H ) | |
Lens | ||
Focal Length | 3.6mm | |
Focus & Type | Fixed (M12) | |
Night Vision | ||
Infrared LED | 3 Array IR LED, 20M IR Range | |
IR Status | Under 10 Lux by CDS | |
IR Power On | CDS Auto Control | |
Low illumination | 0.1Lux @F2.0, 0 Lux with IR LED on | |
Day & Night | Auto (ICR) / Color / B&W | |
Camera Features | ||
OSD Menu Language | EN, CN, DE, FRA, IT, ES, PL, RU, PT, NL, TR, JP | |
White Balance | Auto/Manual | |
Gain Control | Auto | |
Noise Reduction | 3D NR | |
WDR | DWDR | |
Picture Adjustment | Yes | |
General | ||
Waterproof | Plastic Housing, Indoor only | |
Working Temperature | -10℃~50℃, RH95% Max | |
Power Source | DC12V±10%, 500mA | |
Dimension | Size: Φ100×92mm | |
Weight | 0.2Kg |
